1．     将常通开关拨到下面，露出“圆圈”位置，此时定时功能开。

 2．     校对当前时刻。顺时针旋转刻度盘，让箭头指向当前时刻。

 3．     拨动插片设置程序。每个插片为15分钟，按到最下面时该段时间设置为接通。

 4．     把本定时器插入电源，表示定时器进入工作状态，再把用电器插头插入定时器插座，打开用电器开关即可。

 Turn the switch to“”to enable the timing function.

1. Adjust current time,and then turn the dial clockwise to make the arrowhead point at the position of current time.
2. Set up timing program by pulling patches.Each of the patches indicates 15 minutes power on or off. The timer powers on when the patch stays outmost side.
3. Plug in then the timer is working.Plug the electrical appliance into the timer and power it on.

 譬如：现在是早上8:00，您想让用电器在10:15~11:00工作，您就旋转刻度盘，让箭头指向8:00，再把10:15到11：00的三个插片按到最下面（如图示），用电器就能在那段时间内自动工作了。如果需要，您可以每天进行最多48段编程，让用电器在一天的不同时段自动运行。

如暂时不需要定时功能，可把常通开关拨到上面，露出“I”标志，此时定时功能关，电路处于常通状态。

The current time is 8:00 am,and you want the electrical appliance to work from 10:15 am to 11:00 am.First,turn the dial clockwise to make the arrowhead point at 9:00 am.Then pull out the three patches between 10:15 am to 11:00 am to outmost position(see the picture).The plugged in electrical appliances can work from 10:15 am to 11:00 am automatically.You can program the automatically.
Turn the switch back to“I”to disable the timing function and power on the timer.

 注意事项：Warning

 ※本品所接电器功率总和不得超过额定功率；

 ※本品断电后必须重新校队当前时刻；

※除非改变设置，否则每天保持一致的程序；

※请勿擅自拆卸定时器后盖。

 ※The total power of the electrical appliances connected the the timer can not exceed the timer’s rated power capability.

 ※Readjust current time if power of the timer turns off.

 ※The timing program keeps unchanged unless setup changes.

 ※Do not dismantle the back cover from the timer.
