品牌：lyontek来扬
型号：LY61L6416B
64K X 16 BIT HIGH SPEED CMOS SRAM
Features General Description
|
Fast access time : 25ns Low power consumption: Operating current : 50mA (TYP.) Standby current : 1.5µA( (TYP.) Single 3.3V power supply All inputs and outputs TTL compatible Fully static operation Tri-state output Data byte control : LB# (DQ0 ~ DQ7) UB# (DQ8 ~ DQ15) Data retention voltage : 1.5V (MIN.) Green package available Package : 44-pin 400 mil TSOP-II |
TheLY61L6416Bis a 1,048,576-bit low power CMOS static random access memory organized as 65,536 words by 16 bits. It is fabricated using very high performance, high reliability CMOS technology. Its standby current is stable within the range of operating temperature.
|
Key Parameters
| Item No. | Configuration | Power Supply | Isb | Package |
| LY6164 | 8K × 8 | 5V | 1.0mA(typ) | 28 sTSOP (8 × 13.4) |
| LY61256 | 32K × 8 | 5V | 0.5mA(typ) | 28 sTSOP (8 × 13.4) |
| LY61L256 | 32K × 8 | 3.3V | 0.5mA(typ) | 28 sTSOP (8 × 13.4) |
| LY61L1288 | 128K × 8 | 3.3V | 0.6mA(typ) | 32 sTSOP (8 × 13.4) |
| LY611024 | 128K × 8 | 5V | 1.0mA(typ) | 32 SOJ |
| LY61L1024 | 128K × 8 | 3.3V | 0.6mA(typ) | 32 SOJ |
| LY616416 | 64K × 16 | 5V | 0.1mA(typ) | 44 TSOP II |
| LY61L6416 | 64K × 16 | 3.3V | 0.6mA(typ) | 44 TSOP II |
| LY61L6416A | 64K × 16 | 3.3V | 2mA(typ) | 44 TSOP II |
| LY61L6416B | 64K × 16 | 3.3V | 1.5μA(typ) | 44 TSOP II |
| LY612568 | 256K × 8 | 5V | 1.0mA(typ) | 44 TSOP-II |
| LY61L2568A | 256K × 8 | 3.3V | 0.5mA(typ) | 44 TSOP-II |
| LY6112816 | 128K × 16 | 5V | 1.0mA(typ) | 44 TSOP II |
| LY61L12816A | 128K × 16 | 3.3V | 2mA(typ) | 44 TSOP II |
