联泳96650模组+索尼323镜头模组

Main key function
1.Power key: long press to power on or power off
2.Menu Key: In standby mode short press once to enter recording menu, press again to enter the system Settings menu
3.Mode Key: Long press menu button to switch between the video/photo/playback three modes
4.OK key:In standby mode short press to open or close the video,confirm the current selection in the menu setting
Shortcut key：
1.Up key or Down key: in standby mode you can enlarged or reduced focal length by up or down key.
2.Down key: in standby mode or short video process short press once to close the MIC recording
3.Lock key: during the recording, short press the lock key once, manually locking the current video file, the locking video file will not be replaced by the cyclic video

Quick Guide：
1. Note: Please choose the brand of Micro SD card (CLASS 10), please format it before using this camera on the computer, ordinary neutral cards can not be guaranteed to work properly.
2. Turn on and off Video and recording
After connection with car charger, you can ignite the car that automatically start recording. Turn off car that automatically shutdown and preserve video in the memory card, press OK button to stop recording. If not connecting car charger, you can long press POWER button to turn on or turn off.
3. Storage and playback
After finishing record, you can use USB Cable to connect the computer that preserve and play video. Also you can take out the memory card and use the card reader to read video data.
Use Introduction
1.Capture Mode
In the state of non-recording and power on, you can long press the MODE key once to enter the capture mode. In the state of capture mode, you can press the OK button to take the picture
2. Playback Mode
In the state of non-recording , you can long press the MODE key twice to enter the Playback mode. Press the up and down button to choose what you need to play the video or scan pictures taken, and press the OK button that can play. With the state of playing video, you can press the up and down button to fast forward and rewind for video. short press UP / DOWN key to louder or lower voice control . You can press the MODE button twice to exit play.
3. Capture Mode Setting :
In the state of non-recording, you can long press the MODE key once to enter capture mode, and then press MENU key again once enter into capture setting Page (as shown below),

and choose up and down button to set the capture mode , press OK to confirm.
4. Main functions and system settings
A．In the state of non-recording , you can press the MENU key once enter to video setting(as shown below),

and choose the up and down key to set the video mode.
B. Press the MENU key twice enter into system page, and then choose the UP and DOWN key to set the system, and repress the MENU key to exit setting.

Accessories: User Manual, USB Cable, Car Charger(built-in 12V change 5V adapter), Car Holder , GPS mould (optional)
Functions Introduction

● Loop record

When you insert TF card to record video, the video would cover the last before a video, and always continue to recording that you can not worried about removing manually the full video.

● G-Sensor

When the car collision, current video will be saved. When this file is looping record, it will not be deleted and the key icon appear in the screen at this time.

● Timing off-screen
In order to guaranteed not to be effected by the ray of light of recorder, you can choose to turn off the screen, press any key that can recover.

● Parking Monitor

当：开启停车模式功能后，当车身受到震动会自动

：开启停车模式功能后，当车身受到震动会自动
After turn on parking monitor and the car does not start, the recorder will automatically start and record the emergency after shaking. The recording will automatically shut down after a few seconds.(when you are driving, we suggest this feature is closed, otherwise it will cause the card is full)

● Precautions

1. Please insert TF card before recording.

2. Please use secondary USB car charger for the power of DVR, 12V turn to 5V adapter will be included in this car charger. If the output voltage is bigger than 5V, it will burn DVR.
