HDMI分配器1分2 4K*2K 塑料壳    HDMI SPLITTER 1x2 4k

HDMI Splitter 1X2
"Introduction"
HDMI Splitter 1 into 2 out, so that an HDMI port to allocate two HDMI ports high-definition audio and video distributor.
Allows for distribution of set-top boxes, DVD players, D-VHS players and other HDTV devices with HDMI signals in a two-way, simultaneous, HDMI output.
Users can output a single signal can also be connected to high-definition projectors, DLP, LCD high-definition television and other audio equipment.






















"Selling point"
1: Green, passive work
Using the latest energy-saving technologies, the minimum power is only 1W, easily obtainable from the HDMI device, and now we can say goodbye to the power supply, more environmentally friendly and more stable.
2: Full support for HDMI 1080P 3D and so on
Can display vertical pixels up to 1080 lines 3D HD output. Support Blu-ray, PS3 and other multimedia HDMI 3D output device. Let wonderful 3D world at your fingertips.
3: Standard HDMI specification, HDCP compliant
Support all HDMI standard features, including Full HD 1080p, color depth, lip sync, CEC. The system
It also supports all high-resolution multichannel audio formats including Dolby Digital Plus, 7.1 LPCM, Dolby TrueHD, and
DTS Master Audio .....











"parameter"
Support HDMI version: HDMI1.3
Support HDCP version: HDCP1.2
HDMI Resolution: 480i @ 60Hz, 480p @ 60Hz, 576i @ 50Hz, 576p @ 50Hz, 720p @ 50/60 Hz, 1080i @ 50/60 Hz, 1080p @ 50/60 Hz, 1080P 24Hz 3D, 720 60Hz 3D
Support video color format: 24 / dark 30 / dark 36
Support audio formats: DTS-HD / Dolby-true HD / LPCM7.1 / DTS / Dolby-AC3 / DSD
The maximum transmission rate: 10.2Gbps
Audio signal transmission format: left and right stereo audio
Input and output TMDS signal: 0.5 ~ 1.5Vp-p (TMDS)
Input and output DDC signal: 5Vp-p (TTL)
Input cable length: ≤5m (AWG26 HDMI1.3 cable standard)
Output cable length: ≤5m (AWG26 HDMI1.3 cable standard)
Size (length × width × height): 75mm × 56mm × 15mm
Material: ABS
Colour: Black
