| 包装方式 | 小白盒 |
| 工作电压 | DC12V（内置27A12V电池一颗） |
| 工作电流 | 10mA@12V |
| 辐射功率 | 10mw@12V |
| 发射频率 | 433MHZ |
| 传输距离 | 50-100M（空阔地，接收装置灵敏度为负100dbm） |
| 编码器类型 | 固定码.学习码.部分滚动码 |
| 颜色 | 黑色 |
| 功能 | 拷贝遥控/对考遥控/复制钥匙 |
| 尺寸 | 69*43*12毫米 |
| 重量 | 24克 |
| 应用范围 | 遥控器应用广泛.遥控电动伸缩门、升降机，遥控道闸挡车器、遥控卷帘门、车库门、平移门、遥控LED灯、 遥控烟花点火器、遥控客车门，防盗报警器、电动门报警器、MP3摩托车防盗报警器等 |
可对拷芯片
2260（所有厂商），2262（所有厂商），PT2264（所有厂商），5326（所有厂商）， 527（所有厂商），1527（所有厂商），2240（所有厂商） |
HT6026，HT6012，HT6014，HT600，HT680，HT6010，HT6207，HT640， HT6P12E，HT6P20D，12L-4SC |
| PT2292，12L4SC，SC5262，PLC168，NF9420116，UM3750AM，SMC918，SMC908，1416，5211 |
| HCS101，HCS200，HCS201，HCS300，HCS301 （部分代码） |
可对拷的国外品牌
BFT MITTO2 MITTO4 (old version) . BENINCA TO GO WV .DOORHAN TX4 .NICE FLORS .V2 .NOVOFERM .FAAC XT4 433RC
KEY TXB-42R .ATA PTX4 .GBD AU1600 .Nice-Smilo .ROSSI .MotorLine MX4SP DSM .DEA MIO TR2 .Peccinin TX3C
Centurion NOVA .AN MOTOR AT-4 FADINI JUBI .Hiland .CAMEK323 .AK327A .CAME-TOP432NA .CAME-TOP434NA .CAME-TOP432EV .CAME-TOP432S .CAME-TAM432SA |
Here is the way of copy
Memory clearance
1.Press button 1 and 2simultaneousuntil LED flflashes 3 times
2. Release button 2 (Keep pressing button 1), and press button 2 slowly for 3 times, LED flflashes quickly.
3. Release both button, the duplicator is ready for copying
Duplicating
Put duplicator aside of original transmitter, as close as possible.
Fixed code remote control:
Press and hold button 1 of original transmitter, then press and hold button 1 of duplicator until you see the duplicator’s
LED flflashes means the duplicating succeed.
Repeat above step to the rest buttons. The duplicator will work after duplicating.
Rolling code remote control:
Press and hold button 1 of original transmitter, then press and hold button 1 of duplicator until you see the duplicator’s
LED flflashes means the duplicating succeed.
Once 1 button duplicated, the rest buttons will generate automatically, please follow original receiver manual to insert
the new duplicator on the receiver.
Special programming steps for BFT MITTO2 & MITTO4 (old version)
1, memory clearance
2, Press and hold button 1 of duplicator till LED flashes twice and off, press button 2 once while keep holding button 1,
the duplicator into BFT copying mode
3,Press and hold button 1st &2nd of BFT simultaneous (seed code sending mode), LED on duplicator will flashes twice
and off, release both BFT buttons and then press any button of BFT, LED on duplicator will flashes three times then stay
on, which indicates BFT copying done.
Remarks: button 1 of duplicator keep pressed from step 2 till 3 done.
Duplicator to send seed code of BFT: Press button 1 & 4 simultaneous.
Resume
If you erase the code by mistake, you can resume it by pressing and hold both of the "3" and "4" button on the remote
controllers at the same time, after 10 seconds, the LED flflashes 2 times and turn offffwhich indicates the code of the copy
remote controller is resumed.
Remarks:
For fixed code &learning code remote controls, the duplicator will work after duplicating.
But for the rolling code brand listed above, please follow the original manual to program the duplicator to receiver after
duplicating
