主要技术参数 |
SPECIFICATIONS |
Units |
B50100 |
|
滑枕最大插削长度 |
Max. ram slotting length |
mm |
1000(内孔850) |
|
滑枕运动次数 |
Ram moving frequency per minute |
times/min |
4-25/7-25 |
|
刀头支撑面到床身前壁间距离 |
Distance from cutter head to column surface |
mm |
1120 |
|
滑枕底端到工作台面距离 |
Distance between ram lower end to table surface |
mm |
1140 |
|
工作台直径 |
Table diameter |
mm |
1250 |
|
工作台纵向行程 |
Table longitudinal travel |
mm |
1200 |
|
工作台横向行程 |
Table cross travel |
mm |
1000 |
|
工作台最大回转角度 |
Table rotation angle |
° |
360 |
|
工作台进给范围 |
Table feed range (longitudinal and crossl) |
mm |
0.2-5 |
|
工作台回转进给范围 |
Table rotary feed range |
mm |
0.4-10 |
|
主电机功率 |
Main motor power |
kw |
37 |
|
机床重量 |
Machine weight |
kg |
22000 |
|
外形尺寸(长×宽×高) |
Overall dimension |
mm |
4400*2830*5730
|
