资料链接：https://pan.baidu.com/s/1ddm1KXfw2sSsXOL_-P9_wQ?pwd=8888 提取码：8888
电流：50A/100A
电压：3.3-5V
工作温度：-40°C ~ 150°C
特点和优点：
？噪声性能，通过专有的放大器和滤波器设计技术
？集成屏蔽大大降低电容耦合电流导体死于高dV/dt信号，和防止失调在高边漂移，高电压应用
？总输出增益和偏移误差的改善修剪过的温度
？体积小，易于安装能力
？高可靠性的单片霍尔IC
？低功耗：100μΩ内部导体电阻
？隔离允许使用经济、高边
目前在高电压系统传感
？3至5.5 V单电源供电
？120千赫典型带宽
？响应阶跃输入电流3μ输出上升时间
？输出电压与交流或直流电流成比例
？精确裁切工厂
？稳定的输出偏置电压
？近零的磁滞
Features and Benefits
Industry-leading noise performance through proprietary
amplifier and filter design techniques
Integrated shield greatly reduces capacitive coupling from
current conductor to die due to high dV/dt signals, and
prevents offset drift in high-side, high voltage applications
Total output error improvement through gain and offset
trim over temperature
Small package size, with easy mounting capability
Monolithic Hall IC for high reliability
Ultra-low power loss: 100 μΩ internal conductor resistance
Galvanic isolation allows use in economical, high-side
current sensing in high voltage systems
3.0 to 5.5 V, single supply operation
120 kHz typical bandwidth
3 μs output rise time in response to step input current
Output voltage proportional to AC or DC currents
Factory-trimmed for accuracy
Extremely stable output offset voltage
Nearly zero magnetic hysteresis
