System Solutions

Chipset

8632

Sensor

SCF2009,1/3 inches CMOS

Operating System

Linux

Video

Video Encoding

H.265

Frame Rate

15 fps

Resolution

400W(2316H*1308) 360P(640*360)

Illumination

0.02Lux@(2.0,AGC ON),0Lux with IR

Video Bit Rate

HD: 1Mbps
SD: 384Kbps

Lens

6mm

Basic Functions

Mirror/Turn

Support

Noise Reduction/

Dynamic Range

3D Noise reduction/72DB

Movement Tracking

Support

Voice Intercom

Support two-way voice intercom

Audio input

1 pcs MIC

Audio Output

1 pcs Speaker

Anti-flicker

Support Outdoor /50 Hz /60Hz 3 types

Indicator

not

Floodlight

6 pcs floodlight

Infrared Light

6 pcs IR Led

Night Vision Mode

IR-CUT Auto Switch

Movement Detection

Support

Reset

A key for reset

Local Storage

1 pcs TF（Micro SD）Storage interface，support TF cart storage，Connect video/event recording， Maximum support 128G TF card

Network

WIFI

2.4G

Wired connection

Standard

Add Method

Support QR code scanning, fast matching, AP, etc.

Network Protocol

HTTP,HTPPS,TCP,IPV4,IPV6,UDP,RTSP,ICMP,RTP,DHCP,ARP,DNS,QOS

Value-added Services

Tuya Cloud Storage

Support continuous recording/event recording

Amazon Alexa

Support（ Optional）

Google assistant

Support（ Optional）

Power Supply

Powered by

5V

Power consumption

<0.8W

Environment

Working Temperature

-20°C ~ 80°CNon-condensing

Working humidity

10% ~ 95% Non-condensing

APP

1. 1.      Adopt Tuya Smart Cloud Platform, financial-grade security system;
2. 2.      Support IOS, Android system, multi-language, multi-category, universal, no need to worry about mobile phone adaptation;
3. 3.      Support remote online upgrade, remote OTA online upgrade can be easily realized through Tuya Cloud, and experience the latest version in the first time;
4. 4.      Support Tuya cloud storage,and can select Amazon Echo/ Google Chromecast service;
