| CPU | Intel® Baytrail SoC Processor J1900 J1900, QC, 2.00GHz, 10W |
|---|---|
| Chipset | SoC |
| BIOS | AMI SPI 64 Mbit |
| Dimensions | Mini-ITX (6.7-in x 6.7-in, 17.0 cm x 17.0 cm) |
|---|
| Technology | Single Channel DDR3L 1333 MHz |
|---|---|
| Capacity | 8GB |
| Socket | 1 x 204-pin SO-DIMM |
| Controller | Intel® Gen7 Graphics DX 11 |
|---|---|
| HDMI | HDMI 1.4a Max resolution up to 1920 x 1200@60Hz |
| VGA | Max resolution up to 1920x1200@60Hz |
| LVDS | Dual channel 24 bit up to 1920x1200@60Hz |
| MultiDisplay | Dual Display |
| PCIe | 1 x PCIe x1 (Gen2) |
|---|---|
| mini-PCIe | 1 x Full/Half size with PCIe x1 and USB 2.0 |
| Interface | Realtek ALC887, High Definition Audio. Line-out,Mic-in |
|---|
| Controller/ Speed | 2 x Realtek RTL8111G/RTL8111H-CG with 10/100/1000 Mbps |
|---|---|
| Connector | 2 x RJ-45 |
| HDMI | 1 x HDMI 1.4a |
|---|---|
| VGA | 1 (shared with internal VGA) |
| Ethernet | 2 x 1 Gigabit LAN |
| USB | 1 x USB 3.0, 3 x USB 2.0 |
| Audio | 2 (Mic-in, Line-out) |
| DC Jack | 1 |
| USB | 5 x USB 2.0 (2 x 2.54 pitch header, 1 x USB 2.0 Type-A vertical con) |
|---|---|
| COM | COM1, 2, 4, 5, 6(RS-232), COM3 (RS-232/422/485) |
| Parallel | 1 (shared with GPIO) |
| GPIO | 8 x GPI, 8 x GPO (shared with LPT header) |
| TPM | TPM Header |
| LVDS | 1 |
| VGA | 1 x Header (shared with VGA port) |
| SATA PWR Output | 1 |
| Speaker Header | 1 |
| M.2 | 1x M.2 (Key M, 2242/2260/2280) with shared SATA2 for SSD |
|---|---|
| SATA | 2 x SATA2 (3Gb/s), SATA2_2 shared with M.2 Key M |
| Output | From Super I/O to drag RESETCON# |
|---|---|
| Interval | 256 Segments, 0, 1, 2, ...255sec |
| Input PWR | 12V DC-In (DC Jack) |
|---|---|
| Power On | AT/ATX Supported - AT : Directly PWR on as po wer input ready - ATX : Press button to PWR on after po wer input ready |
| Operating Temp | 0ºC ~ 60ºC |
|---|---|
| Storage Temp | -40° C ~ 85° C |
| Operating Humidity | 5% ~ 90% |
| Storage Humidity | 5% ~ 90% |
