传感器Sensor |
OV 1/2.7 sensor |
备注 |
有效像素Effective Pixels |
1920(H)X 1080(V) |
|
最高清晰度Resolution |
1080P |
|
像素尺寸Pixel Size |
3um X 3um |
|
最低照度Minimum illumination |
0.1LUX |
|
扫描方式Scanning Mode |
Progressive scan |
|
扫描频率H Scanning frequency |
30HZ/25HZ |
|
扫描频率 V Scanning frequency |
60HZ/50HZ |
|
动态范围 Dynamic Range |
80dB |
|
信噪比 SN Ratio |
>=50dB |
|
视频输出格式 Video Format |
MJPG/YUY2 |
|
SENSOR数据输出 Sensor Output |
MIPI |
|
分辨率和帧率 Resolution and Frame rate
|
1920x1080 at 30fps 1280x720 at30fps 1024x768 at 30fps 800x600 at 30fps 640x480 at 30fps |
MJPG |
分辨率和帧率 Resolution and Frame rate
|
1920x1080 at 5fps 1280x720 at 10fps 800x600at20fps 640x480 at 30fps |
YUY2 |
镜头类型 LENS |
2.5mm |
|
镜头参数LES parameters |
M12广角镜头(650nm带通滤光片,HFOV:138 VFOV:75 DFOV:167 ) M12 LENS 650nm filters |
|
连接接口 Connector |
5pin 1.25mm USB2.0插座 connector out |
|
USB接口速度 USB2.0 Speed |
480Mb/S |
|
电源 Power |
5V±5% |
|
功率 Power consumption |
Max 1W |
|
尺寸 Size |
15X 15mm |
|
重量 Weight |
TBD |
|
稳定工作温度Working Temperature |
-30~70 ℃ |
|
储存温度&湿度Storage temperature |
-40~80 ℃/0~90RH |
|
产品标准Product Standard |
USB-IF WHQL RoHS |
|
质保期 warranty |
1 years |
|
