Hardware Spec. Firmware Spec.

Image sensor Type 8.0MP CMOS File Format Movie H.264 （MP4）

Backend chipset（DSP） Manufacturer V3 Photo JPG

Lens Type Fixed focus Photo Resolution 16M/12M/8M/5M/2M

Aperture F5.5

Effective Focal Length f=39mm Movie Resolution "4K (3840*2160) 30FPS,2.7K (2688*1520) 30FPS,

1080P (1920*1080) 60FPS

1080P (1920*1080) 30FPS

720P(1280*720)90FPS，720P(1280*720)60FPS

720P(1280*720)30FPS"

View Angle 90°

Exposure Auto

LCD monitor Size 1.3" HD TFT Focus Fixed Focus

Resolution 240(RGB)×240 Real Time Clock（RTC） Yes

Manufacturer TXD Micro SD card capacity 64GB (SDHC）

Storage media Internal mem 4MB SPI. Webcam（PC cam） YES

External mem Micro SD Mechanical Spec

Interface USB Micro USB Dimension 116*32*23.2mm

Microphone Line in Weight 54.5g

SD card slot Yes Software Application

Button/Switch Power key Software Plug and Play

Previous key/ WIFI key System Requirements

Menu key OS Microsoft Windows XP/Vista/7/8

Next key Hardware Intel/AMD Dual-Core CPU or above

Photo key/ Record key 1GB system memory

2GB free System HD Space

USB 2.0/3.0

Battery

Microphone YES (Built-in + external dual microphone） Capacity Built-in Li-ion batteries 1000mAh

Speaker YES Battery Life More than 1.5Hours
