Front Booster model: XPRO5824G2F2X4W

Operating range: 2.4~2.5GHz; 5.0~5.8GHz

output power: 4000mW (36dBm)

Channel width: 20Mhz&40Mhz&80Mhz

Supported standards: IEEE 802.11b/g/n/a/ac

Operation mode: Bi-directional, half-duplex, time division duplex

Antenna: 2.4G 12dBi/5.8G 10dBi dual band directional antenna

Input terminal connector type: N-K female

Input power: 0~20dBm

Transmit gain: 16 ~ 19dB

Receiver gain: ≤12dB

Noise figure: ≤3.5dB typical

Frequency response: ±1dBoveroperatingrange

Power adapter: 15V/2A DC, 100~240V

Rear Booster model: XPRO5824G2F4X4W

Operating range: 2.4~2.5GHz; 5.0~5.8GHz

output power: 4000mW (36dBm)

Channel width: 20Mhz&40Mhz&80Mhz

Supported standards: IEEE 802.11b/g/n/a/ac

Operation mode: Bi-directional, half-duplex, time division duplex

Antenna: 2.4G 12dBi/5.8G 10dBi dual band directional antenna

Input terminal connector type: N-K female

Input power: 0~20dBm

Transmit gain: 16 ~ 19dB

Receiver gain: ≤12dB

Noise figure: ≤3.5dB typical

Frequency response: ±1dBoveroperatingrange

Power adapter: 15V/2A DC, 100~240V

Operating temperature: -20°C to +65°C

Operating humidity: Up to 75% relative humidity

Material: Cast aluminum + ABS

LED light: Power status LED and activity status LED

Battery：Internal 21.6V 4000mA(86.4Wh)
